Expansion unit for floor heating thermostat 3600 W – Non-programmable

Expansion unit for floor heating thermostat 3600 W – Non-programmable

Name: Expansion unit for floor heating thermostat 3600 W – Non-programmable
Brand: Sinopé Technologies
SKU: TR1310
Price: 159.99 CAD
Availability: InStock

143.99$ 159.99$

TR1310

Product variants

Designed to expand the coverage area of floor heating thermostats when it exceeds 15 A
Equipped with a Class A ground fault circuit interrupter (GFCI)
Includes protection for engineered wood flooring
Can connect up to 10 expansion modules per thermostat

Complete your cart

Compatibility and installation

The non-programmable floor heating expansion module – 3600 W is compatible with all Sinopé floor heating thermostats.

Technical specifications

Dimensions

Height: 12.5 cm (4.93 in)
Width: 7.13 cm (2.81 in)
Depth: 2.35 cm (0.93 in) + 2.4 cm (0.94 in)

Power Supply:

120/208/240 VAC, 50/60 Hz

Maximum Load:

15 A / 1800 W @ 120 V
15 A / 3120 W @ 208 V
15 A / 3600 W @ 240 V
Resistive load only.

Temperature Range:

Setpoint range: 5 °C to 36 °C (41 °F to 97 °F)
Display range: 0 °C to 50 °C (32 °F to 99 °F)
Storage: -20 °C to 50 °C (-4 °F to 122 °F)

Certifications and warranty

3 years limited warranty.

Included in the Box

Expansion Module TR1310
Installation guide – French/English
2 mounting screws
