Zigbee Load Controller 50A
Sold out
Product informations
The RM3250ZB smart electrical load controller lets you control, automate, and optimize energy-intensive electrical equipment. With Zigbee connectivity, it integrates into your smart home ecosystem to help you manage your energy consumption more efficiently.
- Remotely control electrical loads of up to 50 A, depending on voltage and load type, using the Sinopé app.
- Suitable for a wide range of residential and commercial applications, including hot tubs, pool pumps and filters, electric vehicle chargers, outdoor lighting, and irrigation pumps.
- Compatible with Éco Sinopé to participate in demand response programs offered by select energy providers.
- Zigbee 3.0 technology for seamless integration into a compatible smart home ecosystem.
- Built-in timer to automate equipment operation and reduce energy waste.
- Connected load power monitoring for better insight into your energy consumption.
- Geofencing, scenes, and automation features to adapt equipment operation to your daily routines.
A compatible Zigbee gateway is required to access connected features.
How do I enroll my device in Peak Saver?
1. Download the free Neviweb app by Sinopé.
2. Add your devices in the app and select the Peak Saver option in Éco Sinopé.
Connect it to the Sinopé gateway to take advantage of its exclusive features
Your home, your ecosystem
This smart thermostat from Sinopé integrates easily into your ecosystem.
Add it to Neviweb for maximum features.
Features and technical specifications
Designed for savings
Actions tailored to your reality.
With time and sunrise/sunset automations, you can align the operation of the charge controller with your schedule, whatever it may be.
Consume better to pay less.
Thanks to consumption graphs, you can monitor the use of your energy-consuming devices in real time. See how rewarding it is to use smart devices.
Technical specifications
Dimensions:
- Height: 18.4 cm (7.26 in)
- Width: 12.2 cm (4.8 in)
- Depth: 5.5 cm (2.15 in)
Communication:
- Protocol: Zigbee 3.0
- Frequency: 2.4 GHz
- Emission power: +20 dBm
- Receiver sensitivity: -108 dBm
- Encryption key: AES-128
Connectivity Requirements:
- GT130 gateway, compatible Zigbee gateway, or Sedna Wi-Fi valve (2nd gen.)
- Smartphone or tablet
- Neviweb app available for free in the App Store and Google Play
Power Supply:
- 120/208/240/277/347 Vac, 50/60 Hz
- Maximum wire gauge: 6 AWG
Consumption:
- Activated load: 0.5 W @ 120 – 240 Vac
- Deactivated load: 0.47 W @ 120 – 240 Vac
Temperatures:
- Operating temperature: 0 °C to 40 °C (32 °F to 104 °F)
- Storage: -20 °C to 50 °C (-4 °F to 122 °F)
Certifications and warranty
Tested in accordance with ANSI/UL Std.916
Certified under CAN/CSA Std. C22.2 No205
3 years limited warranty.
Included in the box
- RM3250ZB electrical load controller
- Installation guide – English version
- Installation guide – French version
- Template
- 2 screws
